Stainless Steel Filler Wire

430 / 430L

SUPERMIG 430


DESCRIPTION : SUPERMIG 430 is a ER430/G17 type solid MAG welding wire supplied precision layer wound. Suitable for use with Ar-CO2 mix shielding gases. It is used for many surfacing applications. Welding with SUPERMIG 430 usually required pre heating and post weld heat treatment .



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 430


DESCRIPTION : SUPERTIG 430 is a 16 Cr (wt.%) alloy & the composition is balanced by providing sufficient chromium to give adequate corrosion resistance for the usual applications, and yet retain sufficient ductility in the heat-treated condition. Welding with ER430 usually requires preheating and postweld heat treatment.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish



KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 430 ER 430 ≥400 ≥450 ≥15% ≥27 DC (+)
SUPERTIG 430 ER 430 ≥400 ≥450 ≥15% ≥27 DC (-)



SUPERMIG 430 - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 430 - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
