DESCRIPTION : SUPER MIG 2594 is a G 25 9 4 N L type solid MIG welding wire, supplied precision layer wound, depositing a C-25Cr10Ni4Mo weld metal suitable for use with Ar+2%O2 or Ar+0.5…5%CO2 mixed shielding gases. SUPER MIG 2594 is used for the welding of Super-Duplex stainless steels, mainly used in Offshore applications, paper industry, oil industry and artificial manure production. It is often used for root pass welding of 22%Cr standard duplex steels for critical applications, also for the welding of low carbon super martensitic 13%Cr steels. SUPER MIG 2594 has a very good resistance to general corrosion, the weld metal has a high resistance to pitting combined with a good resistance to crevice corrosion as well as stress corrosion cracking. The nickel over matches the parent material by 2-3% to provide an optimum balance of austenite and ferrite in the as welded condition.
SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)
FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish
DESCRIPTION : SUPERTIG 2594 is a W 25 9 4 N L type solid TIG welding rod depositing a C-25Cr 10Ni 4Mo weld metal suitable for use mainly with Ar shielding gas. SUPERTIG 2594 is used for the welding of super-duplex stainless steels. Mainly used in offshore applications, paper industry, oil industry and in the production of artificial manure. Used for root pass welding of 22%Cr standard duplex steels for critical applications, and for the welding of low carbon super martensitic 13%Cr steels.
SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)
FINISH : Bright Finish
|Product Name||AWS/SFA||Yield Strength N/mm2||Tensile Strength N/mm2||Elongation A5||Impact Energy ISO-V(J) 20° C||Welding Conditions|
|SUPERMIG 2594||AWS A5.9: ER 2594 EN ISO 14343-A: G 25 9 4 N L||≥ 550||≥ 800||≥ 25||≥ 80||DC+|
SUPERMIG 2594 - TYPE OF PACKING :
|SD 300 / BS 300||11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.|
|SD 200||4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.|
|SD 100||0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.|
|Mig Wire in Drum||In Drums of 100-250 Kgs (200-550 Lbs)|
SUPERTIG 2594 - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
