Stainless Steel Filler Wire

308Si / 308LSi

SUPERMIG 308LSi


DESCRIPTION : SUPERMIG 308LSi is an extra low carbon 20 Cr/ 9 Ni stainless steel filler wire suitable for MIG welding of austenitic stainless steels such as 18 Cr /8 Ni type, AISI 301, 302, 304, 304L, 308 and 308L type of steels. Excellent corrosion resistance and good mechanical properties.SUPERMIG 308LSi is used for welding of 304 and 304L grade stainless steel. The weld metal provides good corrosion resistance to intergranular attack from a range of liquid media. It is used for a wide range of applications including pipe work and plate fabrication, vessel production etc.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 308LSi


DESCRIPTION : SUPERTIG 308LSi is a 20 Cr / 10 Ni stainless steel TIG welding wire similar in composition to ER 308LSi, suitable for welding of austenitic stainless steels such as 18 Cr/ 8 Ni type, AISI 304, 304L and 308LSi type of steels. Excellent corrosion resistance and good mechanical properties.


SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 308LSi ER 308LSi ≥350 ≥520 ≥35% ≥60 DC (+)
SUPERTIG 308LSi ER 308LSi ≥350 ≥520 ≥35% ≥60 DC (+)



SUPERMIG 308LSi - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 308LSi - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
