Stainless Steel Filler Wire – SUPERMIG 308L, SUPERTIG 308L and SUPERSAW 308L

308L

SUPERMIG 308L

DESCRIPTION : SUPERMIG 308L is an extra low carbon 20 Cr/ 9 Ni stainless steel welding consumable suitable for MIG welding of austenitic stainless steels such as 18 Cr /8 Ni type, AISI 301, 302, 304, 304L, 308 and 308L type of steels.

SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)

FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish

SUPERTIG 308L

DESCRIPTION : SUPERTIG 308L is a 20 Cr / 10 Ni stainless steel TIG welding wire similar in composition to ER 308L, suitable for welding of austenitic stainless steels such as 18 Cr/ 8 Ni type, AISI 304, 304L, 308 and 308L type of steels.

SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)

FINISH : Bright Finish

SUPERSAW 308L

DESCRIPTION : SUPERSAW 308L is a 20 Cr / 10 Ni stainless steel submerged arc welding consumable similar in composition to ER 308L, suitable for welding in combination with SAW flux for austenitic stainless steels such as 18 Cr/ 8 Ni type, AISI 304, 304L, 308, 308L, 321 and 347 type of steels.

SIZE RANGE : 1.60 mm to 4.00 mm (0.062” to 0.156”)

KEY SPECIFICATIONS :

Product Name	AWS/SFA	Yield Strength N/mm2	Tensile Strength N/mm2	Elongation A5(%)	Impact Energy ISO-V(J) -20° C	Welding Conditions
SUPERMIG 308L	ER 308L	≥350	≥550	≥35	≥70	DC(+)
SUPERTIG 308L	ER 308L	≥350	≥550	≥35	≥70	DC(-)
SUPERSAW 308L	ER 308L	≥350	≥550	≥35	≥47	-

SUPERMIG 308L - TYPE OF PACKING :

SD 300 / BS 300	11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200	4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100	0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum	In Drums of 100-250 Kgs (200-550 Lbs)

SUPERTIG 308L - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.

SUPERSAW 308L - TYPE OF PACKING : Layer Wound Coils (With Fiber Core)/ Plastic Core, K415 Metal Spools of 25 Kgs./ 50lbs./ 60lbs.
