Stainless Steel Filler Wire

308 / 308H

SUPERMIG 308H


DESCRIPTION : SUPERMIG 308H is suitable for welding AISI 304H austenitic stainless steel and similar steels. It is used mainly in petrochemical industry including the fabrication of pipe and vessel. The higher carbon content results in higher strength at elevated temperatures.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 308H


DESCRIPTION : SUPERTIG 308H is a 20 Cr / 10 Ni stainless steel TIG welding wire similar in composition to ER 308H, suitable for welding of austenitic stainless steels such as 18 Cr/ 8 Ni type, AISI 304H, 308H type of steels. Excellent corrosion resistance and good mechanical properties. Ferrite is controlled between 3% to 8 %. Extra low carbon increases inter-granular corrosion resistance. Excellent crack resistance.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 308H ER 308H ≥350 ≥550 ≥35% ≥70 DC (+)
SUPERTIG 308H ER 308H ≥350 ≥550 ≥35% ≥70 DC (-)
SUPERSAW 308H



SUPERMIG 308H - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 308H - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.



SUPERSAW 308H - TYPE OF PACKING : Layer Wound Coils (With Fiber Core)/ Plastic Core, K415 Metal Spools of 25 Kgs./ 50lbs./ 60lbs.
