Stainless Steel Filler Wire

304L

SUPERMIG 304L


DESCRIPTION : SUPERMIG 304L is an extra low carbon stainless steel filler wire suitable for MIG welding of austenitic stainless steels such as 18 Cr /8 Ni type, AISI 301, 302, 304 and AISI 304L type steels. Excellent corrosion resistance and good mechanical properties.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish.



SUPERTIG 304L


DESCRIPTION : SUPERTIG 304L is an extra low carbon stainless steel TIG rod similar in composition to AISI 304L, suitable for welding of austenitic steels such as AISI 301, 302, 304 and 304L. Excellent corrosion resistance and mechanical properties. Ferrite controlled between 3% to 8 %.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :

Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Welding Conditions
SUPERMIG 304L AISI 304L ≥350 ≥550 ≥35% DC(+)
SUPERTIG 304L AISI 304L ≥350 ≥550 ≥35% ≥47



SUPERMIG 304L - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 304L - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
