Stainless Steel Filler Wire

312

SUPERMIG 312


DESCRIPTION : SUPERMIG 312 is used for welding of steels such as medium and high carbon steels and dissimilar steel combinations. SUPERMIG 312 offer a high tolerance to dilution and therefore particularly suitable for depositing buffer layers prior to surfacing. The deposited weld metal contains ~ 30% delta ferrite in a tough austenitic matrix with high resistance to hot cracking .



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 312


DESCRIPTION : SUPERTIG 312 is a stainless TIG rod suitable for welding or surfacing difficult to weld steels. Suitable for welding buffer layers. The excellent mechanical properties and the notch toughness make SUPERTIG 312 suitable for a wide range of applications .



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 312 ER 312 ≥550 ≥700 ≥22% ≥30 DC (+)
SUPERTIG 312 ER 312 ≥450 ≥650 ≥22% ≥47 DC (-)



SUPERMIG 312 - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 312 - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
