Stainless Steel Filler Wire

309LMo

SUPERMIG 309LMo


DESCRIPTION : SUPERMIG 309LMo is used for TIG / MIG welding of molybdenum containing high alloy and un-allyoed steels. The presence of molybdeunm improves tensile strength and corrosion resistance. Also suitable for welding of stainless steels type AISI 309 series, 316 type clad steels as well as dissimilar metals such as molybdenum containing austenitic stainless steel to carbon steel etc.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 309LMo


DESCRIPTION : SUPERTIG 309LMo is used for welding of dissimilar steels and also used for buffer layers prior to surfacing, when Mo is a required alloying element . SUPERTIG 309LMo is used for the welding of stainless steels to mild and medium tensile steels. It is also used for intermediate layers on structural steel prior to depositing 316L grade stainless steel cladding. SUPERTIG 309LMo is suitable for use mainly with Ar shielding gas.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 309LMo ER 309 Lmo ≥ 350 ≥ 550 ≥ 30 ≥ 55 DC (+)
SUPERTIG 309LMo ER 309 Lmo ≥ 350 ≥ 550 ≥ 30 ≥ 45 DC (-)



SUPERMIG 309LMo  - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 309LMo  - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
