Stainless Steel Filler Wire

2209

SUPERMIG 2209


DESCRIPTION : SUPER MIG 2209 is used for the welding of duplex stainless steels in a range of applications including the fabrication of pipe and plate. The weld metal provides a high resistance to pitting and stress corrosion cracking especially in high chloride media. The nickel is over matches the parent material by 2-3% to provide an optimum balance of austenite and ferrite in the as welded condition.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 2209


DESCRIPTION : SUPERTIG 2209 is a W 22 9 3 NL/ ER 2209 type solid TIG welding rod depositing a low C 22Cr 8Ni 3Mo weld metal. Suitable for use mainly with Ar shielding gas. SUPERTIG 2209 is
used for the welding of duplex stainless steels in a range of applications including the Fabrication of pipe and plate.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 2209 ER 2209 ≥ 480 ≥ 690 ≥ 22% ≥ 50 DC (+)
SUPERTIG 2209 ER 2209 ≥ 480 ≥ 690 ≥ 22 ≥ 50 DC (-)



SUPERMIG 2209 - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 2209 - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
