Stainless Steel Filler Wire

316L

SUPERMIG 316L


DESCRIPTION : SUPERMIG 316L is an extra low carbon 19 Cr/ 12 Ni/ 3 Mo type stainless steel solid wire similar in composition to ER 316L. Suitable for the welding or surfacing of having similar compositions. The weld metal has excellent creep strength upto 850°C. Ferrite controlled between 5 to 10%. The weld metal has excellent crack resistance, intergranular corrosion and creep resistance properties. Excellent mechanical properties and resistance to chemical corrosion.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 316L


DESCRIPTION : SUPERTIG 316L is an extra low carbon 19 Cr/ 12 Ni/ 3 Mo type stainless steel TIG rod similar in composition to ER 316L. Suitable for the welding or surfacing of having similar
compositions. The weld metal has excellent creep strength up to 850°C.. Ferrite controlled between 4 to 8%. The weld metal has excellent crack resistance, intergranular corrosion and creep resistance properties. Excellent mechanical properties.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) -20° C Welding Conditions
SUPERMIG 316L ER 316 L ≥350 ≥520 ≥30 ≥47 DC (+)
SUPERTIG 316L ER 316 L ≥350 ≥510 ≥30 ≥47 DC (-)



SUPERMIG 316L - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 316L - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
