Stainless Steel Electrode

SUPER OPTIMAL 309L-15

For Plastic Tube pack, the outer pack weight will be same as vac & normal pack

For lbs packing :- 2kg :- 5 Lbs, and 5Kg :- 10Lbs, 10kg :- 20Lbs, 20kg :- 40Lbs

For 2kg = 2x5=10kg

For 5kg = 5x4=20kg



International Approvals - SUPER OPTIMAL 309L CE,ABS,BV,LRS,CWB
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact(J)   Welding Conditions Unique Feature (All Vacuum Packed)
Superon 309L E 309L-16 ≥350 ≥550 ≥35 ≥47   Extra strong & tough stainless steel electrode for joining dissimilar steels. Highly recommended for welding hard to weld steels. Extra low carbon content.
Super Stainless 309L E 309L-16 - 600 >35 60   Suitable for welding high temperature steels and as buffer layer before hardfacing. For repairing of machine parts for civil engineering.
SUPER OPTIMAL 309L-15 E309L-15 - ≥550 ≥30 60 at RT DC+ Excellent weldability. Best in class
mechanical properties.
SUPER OPTIMAL 309L E309L-16  - 600 ≥35 60 at RT AC;DC+ Excellent weldability, self peeling slag. Best
in class mechanical properties. Best for
joining dissimilar steels.
SUPER OPTIMAL 309 E309-16 - 590 38 60

Rutile-basic electrode with an austenitic stainless steel deposit containing 15% ferrite- for welding dissimilar steels as stainless steels to low alloyed steels. Also suitable for welding high temperature steels and as buffer layer before hardfacing.
SUPER OPTIMAL 309Cb E309Cb-16 - 590 40 75 at RT AC;DC+ Excellent resistance to chemical corrosion and heat. Weldability with spatter free arc, self -releasing slag.
SUPER OPTIMAL 309LMO-15 E309LMo-15  - 600 35 65   Low carbon basic coated 23Cr 12Ni 2 Mo stainless steel type electrodes, used to weld on AISI 309 & 316L stainless steel and for dissimilar joints between construction, mild steel and stainless steels.
SUPER OPTIMAL 309LMO E309LMo-16 - 600 35 65 at RT AC;DC+ Highly crack resistant. Soft fusion, nice
aspect of the bead, slag lifts by itself
SUPER OPTIMAL 309MO    E309Mo-16 - 600 35 70 - Rutile-basic coated 23Cr 12Ni 2Mo stainless steel type electrode, used to weld on AISI 309 & 316 stainless steels and for dissimilar joints between construction, mild steels and stainless steels.



Packaging Details

Normal Special Packing
Inner Packing Outer Packing
2 & 5Kg Vac Pack 10 & 20Kg 2Kg/5Kg Plastic Tube


For Plastic Tube pack, the outer pack weight will be same as vac & normal pack
for lbs packing :- 2kg :- 5 Lbs, and 5Kg :- 10Lbs, 10kg :- 20Lbs, 20kg :- 40Lbs
for 2kg = 2x5=10kg
for 5kg = 5x4=20kg
