Stainless Steel Electrode

SUPER OPTIMAL 2209-15

For Plastic Tube pack, the outer pack weight will be same as vac & normal pack

For lbs packing :- 2kg :- 5 Lbs, and 5Kg :- 10Lbs, 10kg :- 20Lbs, 20kg :- 40Lbs

For 2kg = 2x5=10kg

For 5kg = 5x4=20kg



SUPER OPTIMAL 2209-15 - Description   :

Basic Coated 22-9-3-N type electrode for joint welding on corrosive resistant duplexsteels. Excellent resistant to intergranular corrosion, pitting and stress corrosion conditions. Low carbon content, excellent weldability, spatter free arc, very smooth bead appearance. The deposited weld metal given excellent ductility dow

Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact (J)   Welding Conditions Unique Feature (All Vacuum Packed)
SUPER OPTIMAL 2209-15 E2209-15  ≥550 ≥750 ≥25 ≥60   Low carbon content, excellent weldability, spatter free arc, very smooth bead appearance.
SUPER OPTIMAL 2209 E2209-16  >500 >700 >25 ≥47 at -40°C AC;DC+ Corrosive resistant duplex-steels. Excellent resistant to intergranular corrosion, pitting and stress corrosion conditions.



Packaging Details

Normal Special Packing
Inner Packing Outer Packing
2 & 5Kg Vac Pack 10 & 20Kg 2Kg/5Kg Plastic Tube
