Stainless Steel Filler Wire

316Si / 316LSi

SUPERMIG 316LSi


DESCRIPTION : SUPERMIG 316LSi is used for welding of 316 and 316L grade stainless steels, in a wide range of applications including the fabrication of pipe and plate. The higher Si level results in a smooth weld bead shape and even appearance with excellent toe blending particularly in fillet welds.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 316LSi


DESCRIPTION : SUPERTIG 316LSi is an extra low carbon 19 Cr/ 12 Ni/ 3 Mo /0.85 Si type stainless steel TIG rod similar in composition to ER 316LSi suitable for the welding or surfacing of havingsimilar compositions.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish

KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 316LSi ER 316LSi ≥ 350 ≥ 510 ≥30% ≥ 80 DC (+)
SUPERTIG 316LSi ER 316LSi ≥ 350 ≥ 510 ≥30% ≥ 47 DC (-)



SUPERMIG 316LSi - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 316LSi - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
