Stainless Steel Filler Wire

309L

SUPERMIG 309L


DESCRIPTION : SUPERMIG 309L is low carbon 25 Cr/ 12 Ni stainless steel solid wire similar in composition to ER 309L. Suitable for welding of austenitic stainless steel such as AISI 309. It is also used to weld dissimilar steels and for buffer layers and buttering 18 Cr/ 8 Ni steels.



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 309L


DESCRIPTION : SUPERTIG 309L is a stainless TIG rod conforming to ER 309L for welding austenitic stainless steels such as AISI 309. It is also used to weld dissimilar steels and for buffer layers and buttering 18 Cr/ 8 Ni steels.



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish





KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) -20° C Welding Conditions
SUPERMIG 309L ER 309 L ≥ 350 ≥ 550 ≥ 30 ≥ 47 DC (+)
SUPERTIG 309L ER 309 L ≥ 350 ≥ 550 ≥ 30 ≥ 47 DC (-)



SUPERMIG 309L - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 309L - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
