Stainless Steel Filler Wire

310

SUPERMIG 310


DESCRIPTION : SUPERMIG 310 weld metal has high temperature ductility , excellent resistance to oxidation at working temperature



SIZE RANGE : 0.60 mm to 1.60 mm (0.025” to 0.062”)



FINISH : Bright Finish, Matte Finish, Semi Bright/Matte Finish



SUPERTIG 310


DESCRIPTION : SUPERTIG 310 is a stainless TIG rod conforming to ER 310 with 25% Cr and 20%  Ni. Suitable for welding steels with similar chemical compositions or dissimilar steels. The weld deposit is fully austenitic. Excellent high temperature corrosion resistance .



SIZE RANGE : 0.80 mm To 5.00 mm (0.030” To 0.196”)



FINISH : Bright Finish



KEY SPECIFICATIONS :
Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2  Elongation A5(%) Impact Energy ISO-V(J) 20° C Welding Conditions
SUPERMIG 310 ER 310 ≥350  ≥550  ≥30% ≥70 DC (+)
SUPERTIG 310 ER 310 ≥350  ≥550  ≥30% ≥47 DC (-)



SUPERMIG 310 - TYPE OF PACKING :

SD 300 / BS 300  11.34 Kgs/ 25 Lbs, 15 Kgs/ 30 Lbs/ 33lbs Layer Wound Plastic/ Metallic Spool.
SD 200  4.54 Kgs/ 10 Lbs Layer Wound Plastic Spool.
SD 100 0.700 Kgs/0.910 /2 lbs Layer Wound Plastic Spool.
Mig Wire in Drum In Drums of 100-250 Kgs (200-550 Lbs)



SUPERTIG 310 - TYPE OF PACKING : In Fiber/ Plastic Tubes of 5kg/ 10lbs, Also available in Bulk.
