Low Alloy Electrode

SUPER OPTIMAL 7010-G

DESCRIPTION & APPLICATIONS :

Cellulosic coated deep penetration electrode for welding of pipes and pipelines, in all positions using conventional and stove pipe techniques. It is characterized by a penetrating, forceful and spray type arc. Excellent arc striking and re-striking. It is suitable for welding root passes, fill and cover passes.



UNIQUE FEATURES :

  • Excellent all position electrode.
  • Best suitable for pipeline welding.
  • Excellent mechanical properties in class.

KEY SPECIFICATIONS :

Product Name AWS/SFA Yield Strength N/mm2 Tensile Strength N/mm2 ) Elongation A5(%) Impact V (J)  Welding Conditions
SUPER OPTIMAL 7010-G E 7010-G ≥420 500-640 ≥24 ≥47 DC(+)
